284223-3

Type:
Automotive connector sheath
Brand:
AMP
Colour:
2.54 mm[.1 in]
Product Description:
24 POS.KIT ASSY FOR AIR BAG (G)

Connector Type Female
Connector System Wire to Wire
Waterproof No
Hybrid connector No
Number of holes 24
Number of rows 2
Body material PA GF
Outlet angle 90°
Main Product Colour Green
Centreline (pitch) 2.54 mm[.1 in]
Product Height 39.9 mm[1.571 in]
Product length 38.3 mm
Product Width 17.6 mm[.693 in]
UL Flame Retardant Rating No
Packaging Method Box
Package Quantity
.63 mm [.025 in] width at male end of connector
Circuit Application Signal
Waterproof Rating
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
